What is a side channel blower and how does it work? Elmo Rietschle G Series Operating Principles

What is a side channel blower? How does a side channel blower produce pressure and vacuum? Learn about the operating principles of the Side Channel Blower and Vacuum technology. Learn more at https://www.gardnerdenver.com/elmorie... How does a side channel blower work? The G-Series side channel blower impeller is mounted directly on the motor shaft for contact free compression. Maximum operational reliability, even at high differential pressures, is ensured by the arrangement of the bearings outside the compression chamber. The gas is taken in through the inlet. As it enters the side channel, the rotating impeller imparts velocity to the gas in the direction of rotation. Centrifugal force in the impeller blades accelerates the gas outward and the pressure increases. Every rotation adds kinetic energy, resulting in further increase of pressure along the side channel. The side channel narrows at the rotor, sweeping the gas off the impeller blades and discharging it through the outlet silencer where it exits the pump. We offer side channel blowers in a wide variety of performance ranges to cover the most varied requirements, up to 3,000 m³/h and differential pressures of up to 1,000 mbar. Advantages of our side channel blower technology include: Reliable and built-to-last Virtually maintenance free Robust yet light-weight For use worldwide (UL/CSA/IEC/EN approval) 50/60 Hz voltage range motors ATEX 94/9 EG Adjustable speed via external or integral converter
