Siemens S7 1500 PLC Hardware Setup| IO Modules, Connectors and Power Ratings Pt. 2

Unboxing a Siemens S7-1500 is only the start. In Part 2 of this series, we move past the CPU to understand the critical hardware components that form the backbone of your automation system. Before we touch a single wire in Part 3, you need to understand how these modules truly work. In this video, we break down: 1. I/O Modules & Bus Connectors: How backplane communication works and why the bus connector is the most important "small" part in your rack. 2. Power Module (PM) vs. System Power Supply (PS): Understanding current ratings and how to choose the right power for your load. 3. Hazardous Ratings: A breakdown of Class I, Div 2 and Zone 2 certifications—essential for oil, gas, and chemical industry applications. 4. The Coding Element Mystery: Why that little plastic "mechanical latch" is your best friend when preventing wiring errors. 5. The 4MB SIMATIC Memory Card: Is it enough for your project? 6. The DVD Included: Why you should NOT try to install TIA Portal from this disk (and what it’s actually for). 0:00 – S7-1500 Hardware Overview 1:30 – Unboxing I/O Modules and Bus Connectors 3:45 – Power Module Ratings & Selection 5:15 – Hazardous Area Classifications (UL HazLoc/FM) 7:30 – Front Connectors & Mechanical Coding Elements 9:45 – The "Secret" DVD: Documentation vs. Software 11:00 – The SIMATIC Memory Card (4MB vs. Larger) 🔗 Watch Part 1 (CPU Unboxing):    • Siemens S7-1500 Hardware Setup 2026: Unbox...   🚀 Professional Automation Training Master Siemens S7-1500 with our customized Online, Remote, or In-Plant courses. 🌐 Website: https://jimstechautomations.com.ng 💬 WhatsApp (Instant Inquiry): https://wa.link/5mij7u 📧 Email: info@jimstechautomations.com.ng 📞 Call: +234 805 026 2118 🔗 LinkedIn:   / jims-tech-automations   #Siemens #S71500 #PLC #IndustrialAutomation #AutomationEngineering #TIAPortal #PLCProgramming #ElectricalEngineering #Engineering2026
