Wiring TST429 Platinum

Wiring One TST429 Clark Synthesis recommends an amplifier rated 125-150 watts per channel at 4 ohms (Pay attention to the 4 ohms!) Attach the red wire to the amplifier’s positive (+) output Attach the black wire to the amplifier’s negative (–) output Wiring Two TST429s Clark Synthesis recommends an amplifier rated 125-150 Watts per channel at 8 ohms (Pay attention to the ohms!) Connect TST #1’s black wire to TST #2’s red wire with a wire nut (you can also solder & use heat shrink tubing) Attach TST #1’s red wire to the amplifier’s positive (+) output Attach TST #2’s black wire to the amplifier’s negative (–) output Wiring Four TST429s Clark Synthesis recommends an amplifier rated 500-600 Watts per channel at 4 ohms (pay attention to the 4 ohms!) Connect TST #1’s black wire to TST #2’s red wire Connect TST #3’s black wire to TST #4’s red wire Connect a cable from the Transduces to the amplifier Connect a red wire to TST #1 & TST #3’s red wires Connect a black wire to TST #2 & TST #4’s black wires Attach the red wire to the amplifier’s positive (+) output Attach the black wire to the amplifier’s negative (–) output Longer runs may require larger gauge wires Older products may have different color wires. Please contact Clark Synthesis for more information. View the TST429 Wiring Diagram: https://clarksynthesis.com/wp-content... For more information contact Clark Synthesis 303-797-7500 info@clarksynthesis.com www.clarksynthesis.com
