[Sensor | Infrared Modules]AMG8833 IR Array Sensor Module BMS26M833

📌AMG8833 IR Array Sensor Module BMS26M833 💻More Information: https://www.bestmodulescorp.com/bms26... 00:00 00:17 DEMO IR Array Sensor Module with 2.8” TFT LCD Shield 00:18 00:24 AMG8833 IR Array Sensor Module BMS26M833 00:25 00:51 Product features 00:52 00:57 Pin Description 00:58 01:02 Hardware Overview 01:03 01:14 Use the 2.8” TFT LCD shield to demonstrate with the BMS26M833 01:15 01:43 Getting Started 01:44 02:48 Open the Arduino IDE 02:49 03:09 DEMO with BMduino-UNO 03:10 03:13 www.BestModulesCorp.com ✒Description The BMS26M833 is an infrared thermopile array module from Best Modules, which developed using the AMG8833 sensor. The module is a high-precision infrared array sensor based on advanced MEMS technology, which can directly output 8×8 temperature array. The detection angle of the module can reach 60 degrees, and the detection distance of the module can reach 7 meters. The module can implement the infrared temperature data reading and other functions using the I2C communication mode via the BMCOM interface. The module is suitable for various applications such as thermal imagers and temperature measuring equipment based on thermal imaging technology, etc. ✒Features ◆ Operating voltage: 3.3V~5.5V ◆ Operating current: 4.5mA @ 5V (normal operating mode) ◆ Temperature detection of two-dimensional area: 8×8 (64pixels) ◆ Refresh frequency: 1Hz or 10Hz ◆ Detection Angle: 60 degrees ◆ Detection Distance: MAX 7 meters ◆ Temperature →Range: 0~80℃ (32~176℉) →Accuracy: ±2.5℃ (±4.5℉) ◆ Comply with RoHS standards ◆ Communication interfaces: →BMCOM×1 (INT, SCL, SDA, VDD and GND) →Communication mode: I2C (address: defaults to 0x68) ◆ Arduino Lib application support ◆ Module size: 36mm×23.3mm×7.5mm 🏢 Best modules corp. 🔗2F, 19, Innovation First Road, Hsinchu Science Park, Taiwan 30076 🤝service@bestmodulescorp.com #IRsensor #InfraredShield #ArrayModules #Modules #BMduino-Shield #IRArraySensorModule #sensor #ArraySensor #ThermopileAarray #Shield #Arduino #BMduino
