U1461 Teardown, Compare and PCB Review

This is a continuation of the review of the U1461A Keysight Insulation Resistance Handheld Resistance meter. In this video I take them apart down to the main PCB and give you a tour in detail, Identifying the components where possible (Where I can find them on the internet) Be warned, this is a one hour video and the second half is a slow and detailed scan over the board (Both Sides) so please dont complain about that. You have been warned. You can easily fast forward or just skip the latter half. In the tear down I also strip my U1272A and U1273A to the same level for a side by side comparison just for fun. The interesting thing about the U1461A is the huge transformer at the top of the board, well away from the banana sockets that is used to generate the high Voltages for the Insulation testing. Components identified during the testing are linked in below for your pleasure. The HYCON HY3131 makes very intersting reading as it explains a great deal of detail as to the workings of a modern Multimeter. this chip is the heart of the ADC for most of the ranges and functions. U1461A Spec Sheet http://literature.cdn.keysight.com/li... 15N06G 15A, 60V N-CHANNEL POWER MOSFET http://www.unisonic.com.tw/datasheet/... IXTA3N120 High Voltage Power MOSFETs http://download.siliconexpert.com/pdf... UF840L8A, 500V, 0.85Ω, N-CHANNEL POWER MOSFET http://www.utc-ic.com/uploadfile/2011... AD8436 Low Cost, Low Power, True RMS-to-DC Converter http://www.analog.com/media/en/techni... MAX4581/82/83 Low-Voltage, CMOS Analog Multiplexers/Switches http://datasheets.maximintegrated.com... CM051/2/3B CMOS Single 8-Channel Analog Multiplexer/ Demultiplexer, 4 channel Differential, 3 Channel A/B http://www.ti.com/lit/ds/symlink/cd40... HYCON 50,000 count DMM Analogue front end http://www.hycontek.com/attachments/D...
