Square wave Generation | Square wave | DAC Programming | Square wave Program

Square wave generation using a Digital-to-Analog Converter (DAC) is achieved by alternating the digital input between maximum (e.g., 0xFF for 8-bit) and minimum 0x00)) values with specific time delays. This toggling produces a repeating 0V to maximum voltage analog output, creating a square wave. Frequency is controlled by adjusting the delay, while amplitude depends on the reference voltage, often viewed on an oscilloscope.  Core Implementation Steps Initialization: Configure the DAC peripheral and the associated GPIO pin as an analog output. Level Toggling: Write the maximum digital value (e.g., 255 for 8-bit or 4095 for 12-bit) to the DAC register for the "High" state and a minimum value (usually 0) for the "Low" state. Timing Control: Introduce a specific delay between these writes using a timer, interrupt, or software delay loop to set the frequency. Repetition: Place the toggling logic in an infinite loop to maintain a continuous waveform. Chapters:- 00:00 Introduction 00:54 DAC Introduction 01:47 Square and Rectangular wave 03:07 Pin function selection for Analog Output 04:46 DAC Convert register 06:28 Code for Square wave 09:11 Output Validation for Square wave 11:05 Rectangular wave Generation    • Keil Software | Keil ide | Working with Ke...      • Pin Functions | PINSEL | Pin function sele...      • Sine wave Generation | Sine wave | DAC Pro...      • Trapezoidal wave Generation | Trapezoidal ...      • Triangle wave Generation | Triangle wave |...      • Staircase wave Generation | Staircase wave...      • Digital to Analog Converter | DAC Operatio...      • Embedded System Course      • Pin Functions | PINSEL | Pin function sele...      • Timers in Embedded System      • Embedded Protocols      • GPIO- General Purpose Input Output      • Bit Masking In Embedded System      • DAC: Digital to Analog Converter      • ARM Cortex      • ARM Play List      • Fundamentals of Embedded System      • C and Embedded C Programming   If you have any questions please write to us email: embeddedsystems2025@gmail.com Don’t forget to Like, Share, and Subscribe for more tutorials on Embedded Systems and Microcontrollers. #dac #analogtodigitalconverter #squarewave #signalgenerator #waveformgenerator #learnembeddedsystems #learnembeddedsystems #embeddedsystems #exploreembeddedsystems #embeddedsolutions
