How to Create Interior Walls in Revit - Basic Revit Architecture Tutorial #02

Basic Revit Architecture Interior And Partition wall Basic Revit #02 In Revit Architecture, drawing a basic interior or partition wall using 5 lines is a simplified method to represent walls in a 2D view, especially in conceptual stages or for quick sketches. Here's how you can do it: 1. Select the Wall Tool Open your Revit project. Navigate to the Architecture tab. Click on the Wall tool. 2. Choose the Wall Type In the Properties palette, select a basic wall type for the interior or partition wall. Adjust the wall's height, location line, and base offset as needed. 3. Draw the First Line (Base of the Wall) Start drawing your wall by clicking on the starting point in your plan view. Drag the line to the desired length, then click again to finish. 4. Draw the Second Line (Top of the Wall) To represent the top line of the wall (for 2D representation), draw a parallel line above the base line. Ensure it maintains the thickness of the wall. 5. Draw the Third Line (Midline for Partition) For a partition wall, draw a line in the middle of the wall's thickness to represent the center of the partition. 6. Draw the Fourth and Fifth Lines (Hatch or Detail Lines) Add two more lines inside the wall boundaries if you want to represent hatching or any other detail (like insulation or specific wall materials) inside the wall structure. 7. Finish and Adjust Use the Modify tools to adjust the lines, if necessary. You can add dimensions or further annotations to clarify the wall’s position and thickness. #revit #architecture #autocaddesign #design #cadsoftware #home #ptscad #cadchannel #caddesign #revitup
