Rotary Type Door Liner Thermoforming Machine

3 station rotary type door liner thermoforming machine for refrigerator project TECHNICAL SPECIFICATIONS No.1 : Loading/Unloading It is the station where the shaped door plastic is taken and the new plate is placed. The frame locks open automatically when the rotating plastic frame arrives at the shaped plastic station, and the operator discharging the product must start with the double hand button after inserting the new plastic. After start, the frame locks are closed automatically. No.2 : Heating This station is heated to 120-150 ° C for the plastic sheet to come into the formable viscosity. The station consists of 3 pieces of oven groups equipped with sufficient quarts heaters. The furnace has a single furnace fixed on the top and the bottom furnaces are designed for safety pre-cautions as 2 furnaces. Additionaly, in the furnaces can be adjustable regionaly heating. So this will help that slot in detail for gasget and shelf holder can be better shaping. No.3 Forming This station is the section where the heated plastic is shaped by means of the vacuum mold. In the station, there is an additional upper frame section for get better shape with servo control. Pneumatic locks are available in the connection details of the main mold. No.4 Side Cutting Machine (optional) The door plastic shaped in the thermoform goes into the guillotine shear with the linear movement of this group after the operator has installed the turning table. It comes back and makes a 90 ° turn. As a result of 4 turns and back and forth movement, the side cutting is completed. These movements are made with the help of FIBRO brand special index rotary table and servo control. SYSTEM COMPONENTS CPU Siemens –Simatic S7-300 Operator Panel Siemens –KTP series (guillotine shear) Safety Siemens –Sirius series Switching equipments Siemens –Sirius group Light Barrier Leuze product group Relay Finder-Weidmuller Butons Schneider-Metal series Electric cabinet EAE Terminals Weidmuller Servo Motor Siemens -1FK7 series Vacuum Pump BUSCH Linear Guides Bosch Rexroth/INA/Schneerberger Pnomatic Festo/SMC System components can be changed according to customer desire Product Dimensions : L : 500 mm – 2000 mm W : 400 mm – 800 mm D : 30 mm – 350 mm Address : Organize Sanayi Bölgesi 14. Cd. No:13 26110 Eskişehir / TURKEY Phone : +90 222 236 21 46 Mobile (English) : +90 544 664 66 26 E-Mail : gem@gem.com.tr Web : www.gem.com.tr
