Shimano Lever Strip Down Assembly M395 M396 M315 M445 Basic Entry Lever Master Cylinder

A video that breaks down and discusses the basic Shimano hydraulic lever. M315 M395 M396 M445, these are all similar in their design. Very basic lever with minimal components. As for parts? Well the top cap is available but things like piston, spring or seals well you're best off looking on ali express. Official spares are limited with Shimano. 0:00 What the video is about 0:11 Bleed port (2mm allen key) 0:50 Top cap bolts (T10 torx) 01:17 Rubber Diaphragm 02:12 Compression nut (8mm) 02:26 Pivot is not serviceable (at least I don't think) 03:37 Reach adjuster (2mm allen key) 04:35 Circlip removal 5:18 Internal parts (rod, washer and piston assembly) 05:55 Piston 06:50 Inspect the bore for marks 07:40 Reassembly begins with piston 08:43 Battery on 43% but dies. . . 08:47 Rod, washer and circlip install 10:02 Reconnecting the lever to rod 11:15 Top cap and blocked holes 13:20 Bleed port bolt (Nip it up, it's probably 1-2nm) 14:28 Finish
