XH-W3001 12V Digital LED Temperature Controller 10A Thermostat NTC

Product model: HW-W3001 Material: Electrical components Temperature measurement range: -50℃-110℃ Temperature control range: -50℃-110℃ Accuracy of temperature measurement: +-0.2℃ Temperature Control Accuracy: +-0.1℃ Input measurement: NTC 10KL = 1m waterproof probe Input power supply: 12V Output power: 120W, 240W, 1500W Output type: direct output Output capacity: maximum 10A Installation hole spacing of housing: 73mm/2.87'' (aperture 4mm) Appearance size: 60mm*45mm*31mm/2.36*1.77*1.22'' Packing weight: 51g Operation Manual: 1. Setting the starting temperature: Press the button once to display the starting temperature. Press the button for about 3 seconds for a long time. The number of starting temperature will flicker. The required temperature can be set by the button up and down. 2. Setting the stop temperature: Press the key once to display the stop temperature. Press the key for about 3 seconds for a long time. The stop temperature number will flicker. The required temperature can be set by the up and down keys. Heating mode: 1. Setting essentials: Start-up temperature stop temperature (program automatically judges working mode as heating mode). 2. Settings: Press the up button for a long time, after flicker, and set the start temperature by the upper and lower keys. Press the down button for a long time, after flicker, and set the stop temperature by the upper and lower keys. Use cases: Control the water heater and stop heating to 51°C. Return the temperature to 41°C and start the heating again. How to set it up: 1. Determine the working mode as heating mode, starting temperature stopping temperature. 2. Press the up key button for a long time. When the temperature value flickers, press the upper and lower buttons to adjust the temperature. The starting temperature is 41°C. 3. Press the down key button long. When the temperature value flickers, the upper and lower keys are pressed to adjust the temperature, and the stop temperature is 51°C
