We Ripped Out EVERYTHING! Complete Electrical Rewire | 2023 Vacationer Caravan

Watch as Jarrod and the team completely rip out EVERYTHING and start from scratch with a total electrical rewire that transforms this van into a serious off-grid machine. The original system was a nightmare with household-style crimps that are completely inappropriate for caravans traveling over corrugations, twisted cable connections on the factory DC charger creating terrible charging performance, messy wiring everywhere, and a Projecta system that needed to go. The team stripped it all out and started fresh with a comprehensive Victron system including a 3KVA MultiPlus inverter, 50A Orion XS DC charger with 16mm twin cable run to the A-frame, 70A MPPT solar controller, Cerbo GX with beautiful touchscreen display, and Tank GX module with brand new RV Electronics float senders for accurate 5-litre increment tank monitoring. The solar upgrade is massive with 1260W total across six panels - keeping the original 2x 210W panels and adding 2x 225W plus 2x 210W panels, all wired in series at 120V for maximum efficiency in shaded conditions. Every single panel is individually fused for compliance, and all fuses are conveniently located under one panel for easy troubleshooting. The power storage features 2x 340AH lithium batteries (680AH total) in a custom welded and painted battery box with IP67 shunt mounted outside and proper battery wiring ensuring balanced discharge. Additional upgrades include a complete fuse panel replacement with LED indicators that light up when fuses blow, new low voltage disconnect controlled by an isolation switch, Victron relay setup for the water pump, new AC wiring runs done properly, felt-taped RJ45 cables for a clean professional look, remote-controlled relay for Starlink Gen 3 power control, and VRM portal setup for remote monitoring and troubleshooting. Jarrod demonstrates the system with an incredible real-world test - running the aircon on full cooling at 16 degrees for THREE HOURS on a 35-degree day while solar was charging, and the batteries only dropped from 96% to 85%! That's just 10% battery drain in three hours with the aircon AND fridge running. The solar then recharged the system back to 100% by 4:30pm. He also shows interesting solar performance data revealing that cloudy days actually produced MORE peak wattage (1009W) than the hot sunny day (985W) due to panel heat creating resistance - a perfect example of real Australian conditions. The complete system is fully Bluetooth enabled for phone control, connected to VRM portal for remote access, and built to last 10+ years. This build shows how JT Electrical Group takes disaster electrical systems and transforms them into reliable, professional off-grid powerhouses - perfect for serious adventures! If you learnt something from this video, make sure to like and subscribe for more caravan and RV electrical content from JT Electrical Group! #VacationerCaravan #CompleteRewire #VictronEnergy #ElectricalDisaster #OffGrid #1260WSolar #JTElectrical
