100 AMPS While Driving! ULTIMATE Victron Setup in Elite Balistic Caravan

Check out this incredibly comprehensive Victron system installed in this Elite Caravans Ballistic! Watch as Jarrod and the team from JT Electrical Group walk through every detail of this professional off-grid powerhouse that's built for serious extended adventures. The power storage features 620AH of lithium across 2x 310AH lithium batteries mounted in an AS 3001 compliant airtight area in the tunnel boot. The complete Victron system includes a 3KVA MultiPlus inverter charger for reliable power output, a 50A DC charger for alternator charging, dual solar controllers with a 30A and 50A unit managing separate roof arrays, plus an additional 20A solar controller for the external Anderson plug connection. Everything is monitored through the comprehensive Cerbo GX with touchscreen display and Victron Bluetooth shunt. The solar setup is impressive with 2x 220W panels and 2x 250W panels on the roof creating dual arrays for maximum efficiency, delivering up to 50 amps. Combined with the 50A DC charger while driving, this van can charge at a total of 100 amps on the move! When plugged into shore power, the system charges at 120 amps for rapid battery replenishment. The team also upgraded the monitoring system with an RV Electronics smart signal converter handling four tanks including front fresh, middle fresh, rear fresh, and rear grey water tanks. Additional upgrades include a reworked fuse panels, a convenient black master switch for the low voltage disconnect, and custom inverter cable routing through the washing machine and drawer area. Jarrod demonstrates the system live with a kettle test showing perfectly balanced battery discharge across both batteries thanks to proper wiring configuration, and reviews the solar performance data showing excellent efficiency from both arrays. This build shows how JT Electrical Group properly integrates high-power systems while maintaining safety and compliance - perfect for serious off-grid adventures! If you learnt something from this video, make sure to like and subscribe for more caravan and RV electrical content from JT Electrical Group! #VictronEnergy #EliteCaravans #Ballistic #OffGrid #DualSolar #LithiumPower #JTElectrical
