Build the 'Minimal UART Computer' on PCB - Simplest Usable PC #2

EDIT: New revision 1.5 out now!    • Building the Minimal CPU System (SAP-1 on ...   Hi, I've built my own Computer from scratch - using nothing but TTL chips, because, well, that's what I wanted to do, I guess! Minimal UART CPU: https://github.com/slu4coder/Minimal-... WHAT YOU FIND HERE: ● Complete CPU design with 8-Bit, 1.84MHz, 0.25Mips, 24KB RAM, UART, TTL logic on PCB ● Block diagram of the CPU and overview of it's instruction set ● KiCAD project files with detailed schematics and PCB layout ● Gerber files for easy PCB manufacturing ● Bill of material (BOM) ● Binary images of the ROM and the CPU's control microcode ● Source code of operating system, demos and games ● Cross-assembler running on Windows More info on this design:    • Simplest Usable PC #1   Music: Hideyatakayanagi - Origin Recurrence - Free Background Music No Copyright Music https://click.dj/freebackgroundmusic/... Hideyatakayanagi:   / hideyatakayanagi   Free Background Music: YouTube: http://goo.gl/fFI0z8 SoundCloud:   / freebmusic   Facebook: http://goo.gl/2otgOU Twitter:   / freebmusic   Google+: http://goo.gl/TybZuK
