Minimal UART CPU Goes FLASH with SSD and File System

EDIT: New revision 1.5 out now!    • Building the Minimal CPU System (SAP-1 on ...   I've built my own Computer from TTL chips. But more than that, this project is about exploring what can be achieved while fighting hard against complexity! My enemy is called feature creep and any new idea has to pass a firewall question: Does it add simplicity? You can follow this journey here on my channel from it's humble beginnings up to my latest 'Minimal UART CPU Design'. Today's video will finally push the limits beyond my design finish line: The Minimal UART CPU goes FLASH and gets a Solid State Drive (SSD) for FREE. GitHub repository: https://github.com/slu4coder/Minimal-... WHAT YOU FIND HERE: ● Complete TTL CPU design: 8bit, 1.84MHz, UART, 32KB RAM, 4KB ROM, 28K SSD ● Block diagram and overview of the CPU's instruction set ● KiCAD project files with detailed schematics and PCB layout ● PCB Gerber files and bill of material (BOM) ● Binary images of ROM (OS, demos and games) and CPU's control microcode ● Cross-assembler running on Windows to write your own programs More info on this CPU design:    • Simplest Usable PC #1   Laptop picture by Icons8: http://icons8.com
