Tailgate Handle Graphic for Wrangler JL/JLU Installation Instructions

Shop at https://www.adventurelifedecals.com Minimum application temperature +40° F Applied decal temperature range -40°F to +180°F Steps: 1. Use a panel tool or flathead screwdriver to remove the cover behind your driver side tail light. 2. Remove the plastic bolt with your 10mm socket or T40 Torx wrench. 3. Pull the tail light straight back to remove it. 4. On the inside of your tailgate, remove the black rubber cover above the JL Wrangler info plate. 5. Use your long T20 Torx wrench to loosen the bolt inside the tailgate. 6. Remove the top piece of the handle by pulling it straight back. 7. Lift the handle up and pull it away. If you have keyless entry, unplug the harness attached to the bottom of the handle. Remove the black plastic piece remaining at the top of the handle holes. 8. Clean the surface with water + soap or water + rubbing alcohol and dry with a microfiber cloth. 9. (Do this in the shade) Remove the graphic from the paper backing. Starting with the tailgate side, align it within the inner edge of the bevel. Press the graphic down onto the flat surface to the left of the handle holes on the tailgate using your hand or squeegee. 10. Using the included blade, cut around the bolt at the bottom and the protruding plastic at the top. This does not need to be precise, just enough to let the graphic lay flat on the tailgate. 11. Still on the tailgate side, press the graphic down onto the remaining flat part of the tailgate. Leave a gap on the right side for air to escape in the next step. 12. Use your heat gun or hair dryer to warm up the material above the recessed area. A little heat goes a long way. While the material is warm and pliable, press it down into the recessed area with your finger. Starting on the left side and pushing the air out toward the right side. 13. Cut out the holes for the handle to go back in. Don't worry about cutting close to the edge of the hole. The excess material can be tucked inside. 14. Pull the graphic towards the tail light and apply it on the quarter panel. 15. Use your blade to cut between the tailgate and the quarter panel. Apply the graphic around the edges. 16. Re-install the handle and tail light.
