In this video we will show you how to use AC15-30 drive scope tool, which allows online application monitoring for the AC15 and AC20 variable speed drives, with a fast oscilloscope and data logging facility. The AC15 provides a low-cost and compact solution for open-loop motor control applications in the 0.37kW to 30kW power range. The AC20 series expands upon the AC15 both in terms of functionality and power ratings, covering the 1.5kW to 180kW power range. The AC30 variable speed drive range has been designed to provide users with exceptional levels of control, from simple open-loop pumps and fans through to closed-loop process line applications. Its flexible and highly modular construction enables a wide range of communications and l/O modules to be easily added as required. The AC30 has been designed with simplicity in mind, but this doesn't compromise its functionality. Integrated macros for a range of applications and PLC functionality enable more capable users to create sophisticated control that would previously have required a separate PLC. Designed for operation in environment class 3C3 and 3C4 for Hydrogen Sulphide (H2S) as standard (tested at 25 pm for 1200 hours) and temperatures up to 50 °C. The AC30 also utilises a DC link choke to reduce line harmonics and is available with an optional integrated EMC filter to C2 1st environment. Note: AC30 power stacks and interchangeable control modules are also available as separate components, offering higher power ratings of up to 450 kW, advanced levels of automation control and greater design flexibility - see the 'AC30 Series (Power Modules]' and "AC30 Series [Control Modules]" pages in the recommended products section for more details. More about Electromechanical and Drives Division Europe: https://prker.co/3N0EubM ▬ Chapters ▬▬▬▬▬▬▬▬▬▬▬ 00:00 Connecting the drive to Scope Tool 02:10 Configure Scope channels 03:20 Scale configuration 04:20 Launch Scope record 05:50 Zoom in function 06:36 Edit trigger and sample rate settings 08:56 Trigger function 10:25 Save scope data 11:43 Add another drive to monitor ▬ Social Media ▬▬▬▬▬▬▬▬▬▬ Parker Hannifin All Social Media: http://parker.com/social Twitter at   / parkerhannifin   Facebook at   / parkerhannifin   LinkedIn at   / parker-hannifin   Instagram at   / parkerhannifin   Subscribe to Parker's Technology Blog at https://blog.parker.com/site/usa/ ▬ About Parker Hannifin: ▬▬▬▬▬▬▬▬▬▬ Parker Hannifin is a Fortune 250 global leader in motion and control technologies. For more than a century, the company has been enabling engineering breakthroughs that lead to a better tomorrow. The company's products are vital to virtually everything that moves or requires control, including the manufacture and processing of raw materials, durable goods, infrastructure development and all forms of transport. Key technology areas are aerospace, climate control, electromechanical, filtration, fluid and gas handling, hydraulics, pneumatics, process control, sealing and shielding and human motion. Traded on the New York Stock Exchange under the symbol "PH,"​ Parker is strategically diversified, value-driven and well-positioned for global growth as the industry consolidator and supplier of choice. http://parker.com https://investors.parker.com/ #ParkerHannifin #ACDriveScope #ACDrive #ACVariableSpeedDrive #SpeedDrive
