“Installing the EvoClean” Things to note before installing: Please avoid installing in environments with temperature fluctuations, excessive dirt and dust, and electrical noise. You’ll need: Drill, Philips head screwdriver, ¼ in hex head drill bit, and a cutting tool for the hose. Install near the laundry machine directly into the studs or with the wall anchors provided. Mount the dispenser onto the mounting bracket. Push down the clips to secure the unit. Secure the bottom with the remaining screw. Connect incoming water supply using fittings provided. Connect outlet to the washing machine using correctly sized PVC hose. Secure with a hose clamp. ROUTING THE PICKUP TUBES Open the cabinet of the EvoClean using the phillips head screw. Install hoses to the check valves before connecting them to the manifold. Push the appropriately sized PVC tubing onto the check valve barb. Secure with cable tie. The eductors are designated from left to right. Warning! Don't connect any chemical hoses to the flush (F) valve. Push the check valve elbow into the eductors and secure with the clip. Install all of the elbows and check valves assemblies. There should be one per chemical being dispensed. Make sure the check valves are installed vertically Then install the in-line check valves between the dispenser and chemical container. Match the flow direction to the arrow on the side. Cut the barbs to the largest compatible size with the intake tubing. Make sure gray check valves are used with alkaline products and blue valves with all other chemicals Place the other end of the hose in the chemical container Next, connect the electrical trigger signals and power. These steps vary depending on the model ordered and are covered in the manual. You have now successfully completed the physical installation of the EvoClean and are ready to begin programming and commissioning of the device. To learn more, please visit www.hydrosystemsco.com LinkedIn: / hydro-systems-company #HydroSystems #chemicaldispensingequipment #proportioningequipment
