Arrow XT™ Ascendant® 107’ Heavy Duty Tractor Drawn Aerial – Staunton Fire and Rescue, VA

Watch Fire Chief Scott Garber walk around the City of Staunton’s Arrow XT™ Tractor Drawn Aerial. The department chose the Arrow XT for durability and a smooth ride, and the added TAK-4® Independent Front and Rear Suspension allows for additional maneuverability. Since this apparatus will be serving as a rescue, the tandem axle was chosen for increased load capacity for rescue equipment, added braking capacity and improved winter driving. The Hercules™ CAFS Self Contained Foam System was chosen for its extinguishment capability since this apparatus will be replacing a true quint. The 107’ Ascendant® Ladder also features a pre-piped waterway that pumps up to 1,500 gpm. CHASSIS Chassis: 67” Arrow XT™ cab Seating capacity: 6 Overall height: 11’1” Overall length: 61’0.75” GVW rating: 88,000 lb Front axle: TAK-4® Independent Front Suspension, 24,000 lb Rear axle: Meritor MT-40-14X, 40,000 lb Engine: Cummins X15, 600 hp, 1,850 torque Safety: Side roll and frontal impact protection Electrical: Command Zone™ Advanced Electronics System BODY Material: Aluminum Shelving: Adjustable, up to 500 lb Doors: AMDOR Rollup Foam system: Hercules™ CAFS Self-Contained Foam System Foam cell: 70 gallons Job No: 34164 Dealership: Atlantic Emergency Solutions
