How to replace Adam’s Skin glove and Adam’s Hand fingers

Turn the Adam's Hand on with a long click on the ThunderCell Battery button. Place the thumb in the intermediate position and press and hold the hand button for 5 seconds to enter "Glove mode" - the fingers will reposition in order to facilitate the donning-doffing of the Adam's Skin glove. Switch the entire prosthetic system off and detach Adam’s Hand from the socket or demo unit. Remove the o-ring at the base of the glove, helping yourself with the tool provided in our toolbox. Remove the glove by grasping it from underneath at wrist height and pulling it towards the Adam’s Hand fingers, turning the inside of the glove outwards. Connect back the device to the Demo Unit/socket and switch the entire prosthetic system on. Place the thumb in lateral position and close the hand, leaving the fingers slightly open. Switch the entire prosthetic system off. Unscrew the M3x16 Torx button screw corresponding to the finger to be replaced with a TX10 screwdriver, which is also provided in our toolbox. Detach the old finger from the palm housing and insert the new finger. Apply Loctite 243 Threadlocker at the end of the thread of the new M3x16 torx screw, and screw it in with a maximum tightening torque of 1.20Nm, using the TX10 torx screwdriver. Switch the device back on, place the thumb in intermediate position If you want to replace the thumb remove the circled screw Enable the Glove Mode by pressing and holding the button on the Adam’s Hand back for 5 seconds. Switch the entire prosthetic system off and detach the hand from the socket/Demo Unit. Fold the Adam's Skin lower part outwards to reduce its length, until the thumb inlet hollow is exposed. Insert the glove, checking that the end of each finger is completely inserted into its housing, then slide the silicone material over the entire finger length. Ensure that the glove fits correctly around the seal. Insert the o-ring over the glove at wrist height, positioning it so that it conforms to the Adam's Skin. This will result in an airtight seal. Turn the system back on to ensure that the hand works properly.
