Wiring TST239 Silver

Wiring One TST239 Clark Synthesis recommends an amplifier rated 100-125 Watts per channel at 4 ohms (Pay attention to the 4 ohms!) Attach the striped wire to the amplifier’s positive (+) output Attach the clear wire to the amplifier’s negative (–) output Wiring Two TST239s Clark Synthesis recommends an amplifier rated 100-125 Watts per channel at 4 ohms (Pay attention to the 4 ohms!) Connect TST #1’s clear wire to TST #2’s striped wire with a wire nut )you can also solder & use heat shrink tubing) Attach TST #1’s striped wire to the amplifier’s positive (+) output Attach TST #2’s clear wire to the amplifier’s negative (–) output Wiring Four TST239s Clark Synthesis recommends an amplifier rated 400-500 Watts per channel at 4 ohms (pay attention to the 4 ohms!) Connect TST #1’s clear wire to TST #2’s striped wire Connect TST #3’s clear wire to TST #4’s striped wire Connect a cable from the Transducers to the amplifier Connect a striped wire to TST #1 & TST #3’s striped wires Connect a clear wire to TST #2 & TST #4’s clear wires Attach the striped wire to the amplifier’s positive (+) output Attach the clear wire to the amplifier’s negative (–) output Older products may have different color wires. Please contact Clark Synthesis for more information. View the TST239 Wiring Diagram: https://clarksynthesis.com/wp-content... For more information contact Clark Synthesis 303-797-7500 info@clarksynthesis.com www.clarksynthesis.com
