#22: 5v Soft-Latch Pushbutton Circuit on a Breadboard

This is the 5v version of video #18 - which was a12v push on, push off, soft latch circuit. It is also an improvement over the previous version and includes detailed description of how the circuit works, as well as how to tailor it to the specific load you want to drive. For a schematic and more detailed information about this project, go to https://breadboardcircuits.com/5v-usb... Also, for recommended breadboarding equipment, breadboarding best practices, and safety tips, please visit the home page at https://www.BreadBoardCircuits.com . #5vSoftLatch #SteveMorrison, #PushOnPushOffCircuit #BreadBoardCircuits, #LogicTruthTables, #LearnElectronics, #Breadboard, #Breadboardprojects The circuit described in this video is for entertainment purposes only and any usage of such circuit or associated information is done so at your own risk and/or liability and should be approved by a licensed Engineer in the appropriate jurisdiction if to be used in any form beyond that of the hobbyist's project bench.
