Modifying ESP8266 Adapter Plate and Flashing the Firmware | SkillSheen

In this video, I will describe the method to modify ESP8266 Adapter Plate and solder 3.3V regulator IC (AMS1117). Apart from that, I will also show the procedure to use USB TTL / ESP Programmer to flash the firmware and code onto ESP8266 soldered on the modified adapter. After modification, you can use any 5V source to power this ESP8266 and it will work as intended. ------------------------------------------------------------------- Links ------------------------------------------------------------------------------ Flashing Tool: https://www.espressif.com/en/support/... and download from the 'Flash Download Tools' Binaries: https://docs.espressif.com/projects/e... and download the 'recommended' CH340 Drivers: https://sparks.gogo.co.nz/ch340.html Board Links: esp32: https://espressif.github.io/arduino-e... esp8266: https://arduino.esp8266.com/stable/pa... AMS1117 Datasheet: https://datasheet.lcsc.com/szlcsc/200... ----------------------------------------------------------------- Chapters ------------------------------------------------------------------------------ --------------_________--------------_________--------------________ All images and logos in this video are the property of their respective owners/brands/organizations and are used under the Fair Use Policy.
