Installation Guide for the Draw-Tite Sportframe Trailer Hitch Receiver on a 2015 Chevrolet Cruze

Click for more info and reviews of this Draw-Tite Trailer Hitch: https://www.etrailer.com/Trailer-Hitc... Check out some similar Trailer Hitch options: https://www.etrailer.com/fitguide.htm Search for other popular Chevrolet Cruze parts and accessories: https://www.etrailer.com/vehicle/2015... https://www.etrailer.com Don’t forget to subscribe!    / etrailertv   Full transcript: https://www.etrailer.com/tv-install-t... Today on this 2015 Chevrolet Cruze, we're going to review and install the Draw Tite Sport Frame Trailer Hitch Receiver, part number 24882. All right, this is what the hitch looks like when it's installed on our Chevy Cruze. You'll notice that you'll only see the receiver opening and the safety chain loops and that's it. The rest of the hitch is hidden behind the bumper. Now, this uses a half inch diameter hitch pin hold or your favorite locking hitch pin. On the bottom here, we have a traditional safety chain loop, which will work great with a wide variety of safety chains. This case, pretty much, if you're going to use on a small trailer, you'll probably have a hook just like this. Hitch capacity wise, it's going to be rated for 200 pounds of tongue weight, which is the weight that pushes down on the hitch from your hitch ball or your accessories. Also, the hitch does have a pull weight of 2,000 pounds for your trailer. Now, you always want to double check with your owner's manual to make sure how much weight your vehicle can carry and pull. This is our inch and a quarter opening, right here, be great for very light towing loads or accessories. Now, a lot of times, you won't use your hitch for trailering purposes or you may never tow a trailer but it's great for an accessory, such as this bicycle rack right here. Next, we'll go ahead and give you some measurements that help you out in some of the selections and accessories, such as that bike rack you just saw or maybe even a cargo carrier. So, from the center of the hitch pin hole to the end of our bumper here, it's going to be about 3-3/4 inches. From the top of the receiver opening down to the ground, looking like about 10-1/4 inches. Now the tools we use for our install's pretty simple; ratchet, a 13mm socket, 11/16 socketboth deep wellFairway long extension and also a torque wrench with a matching 11/16 socket. Now, let's go ahead and cover how we installed our hitch. Now, we got a lot of room to work with underneath our vehicle here and this is also an RS model and that won't interfere with anything as well. Plenty of room, this is actually a really good install to do on your garage floor. First step of our install, is go ahead and lower our exhaust to get a little better working room. To do that, we're going to remove this bolt right here using a 13mm socket. Push up a little bit and pull back. This gives us about a inch or two of working room. Our next step is to install hardware into the frame of the vehicle. We need to install this block and this bolt. The hitch does come with the bolt leader or fish wire tool to help do that. This is going to be pretty easy and simple. Now our hitch is going to attach by using this hole here and this hole here. So, to install our hardware, we'll take our bolt leader, push it through the hole we're going to use and out this larger hole here, which will be our access hole. Make sure you don't pull out the rest of your bolt leader from the original hole. Take your block, push it into the frame, and then take your bolt and thread it on, push it into the frame. Do it one more time using this hole right here. Okay. Now, in this case, we'll go ahead and leave our bolt leaders in place so that when we put the hitch up, if we knock the bolts back in, no big deal, we can pull them back through. Now, we're going to repeat that same process over on our drivers side here, using these two same holes. All right. Now we can go ahead and put our hitch in position. It's a good idea to get an extra set of hands and help put it up there. Now, we're going to take our bolt leaders, put it through the matching holes, and slowly push your hitch up into place, push it over your exhaust and up. Now if you can, push the hitch one way or the other to kind of trap the bolt. Remove your bolt leader and install your conical tooth washer with the teeth facing towards the hitch and then install the nut. We'll do one on each side to help stabilize the hitch. All right. Now, we'll go ahead and remove our other bolt leader and install the rest of our hardware. It'll be the same for all four bolts. Now, we'll go ahead and center up our hitch, which basically is pull it straight back and let the holes kind of guide it. You got a little bit of play, put it the way you want it and then we'll go ahead and tighten down our hardware, using 11/16 socket. Now we'll go ahead and torque the bolts down using a torque wrench
