SOLIDWORK TUTORIAL NO #18 / HOW TO MAKE SQURE THREAD IN SOLIDWORK. ======== IN THIS TUTORIAL I WILL EXPLAIN HOW TO USE THIS HOLE VIZARD FIATURE AND MAKE SQURE THREAD AND YOU CAN MAKE ALL TYPE OF THREAD USE THIS METHOD IN SOLIDWORK. IN THIS TUTORIAL WE MAKE A 1 SQURE PROFILE IN THREAD PROFILE FOLDER.I WIL ALSO GIVE PATH OF THIS THREAD PROFILE FOLDER. (THIS PC)---(LOCAL DRIVE_ C)---(Program Data)---(SOLIDWORKS)---(SOLIDWORKS 2016)---(Thread Profiles) NOW GO INSIDE THIS THREAD PROFILE AND NOW COPY THIS METRIC DIE.SLDLFP FILE AND PASTE IN THIS THREAD PROFILE FOLDER.NOW RENAME THIS FILE AS A METRIC SQURE THREAD AND OPEN IT IN SOLID WORK AND EDIT THIS PROFILE AND MAKE SQURE PROFILE AND DIAMENTION OF THIS PROFILE IS 2*2 Squre shape. IN THIS TUTORIAL WE MAKE THREAD ON OD MEANCE OUTER SURFACE OF CYLINDER IF YOU NEED INSIDE THREAD MEANCE ID (INSIDE DIAMETER) THEN ALL PROCESS SAME BUT COPY METRIC TAP.SLDLFP THIS FOLDER AND EDIT THIS FILE AS A METRIC THREAD SQURE AND OPEN AND EDIT AND MAKE THREAD LOCATION IN CYLINDER INSIDE HOLE THEN SELECT THREAD AND THIS FILE THAN THREAD ARE DONE . IF YOU CAN FACED PROBLEM IN INTERNAL THREADS THAN COMMENT PROBLEM I WILL SOLVE YOUR PROBLEM . IN THIS TUTORIAL WE MAKE SQURE THREAD AND THIS SQURE THREAD DIAMENTION IS PER THREAD HEIGHT AND LENGTH IS STANDARD IN VARIOUS DRAWING DIAMENTION IS LIKE THIS 0.5 * (MULTIPLY) OUR PITCH 1 MM. (IN THIS TUTORIAL FOR EXAMPLE WE USE 1 MM PITCH) 0.5*1 =0.5 DIFFERENT EXAMPLE 0.5*1=0.5 0.5*2 =1 0.5*10=5 0.5*20=10 (this 0.5 will be standard and pitch will be 1,2,10,20) IN VARIOUS TIME THIS DIAMENTION IS CONSIDER LIKE THIS. EXAMPLE P/2 THIS STANDERD FORMULA USE. MEANCE 1 / 2 = 0.5 2 / 2 = 1 10 / 2 = 5 20 / 2 =10 THIS DIAMENTION ARE ONLY FOR SQURE THREAD AND ALL DIAMENTION ARE IN MM. ======== we will learn below tools or features (OPTIONS) IN SOLIDWORK. 1. HOLE VIZARD FEATURE 2. THREAD 3. SQURE THREAD ========= other tutorial link ...... 1.how to make a hexagonal cup using draft feature.    • CREO TUTORIAL #4 /HOW TO MAKE A HEXAGONAL ...   2.how to make a piston in solid work.2020    • SOLID WORK TUTORIAL NO#7 /HOW TO MAKE A PI...   3.how to make a flower pot.    • SOLID WORK TUTORIAL NO#7 /HOW TO MAKE A PI...   4. SOLIDWORK TUTORIAL NO#2 | HOW TO MAKE A SCREW WITH VARIABLE PITCH DIAMENTION.    • SOLIDWORK TUTORIAL NO#2 | HOW TO MAKE A SC...   5. SOLIDWORK TUTORIAL NO#1| HOW TO MAKE A KNURLING OPERATION IN SHAFT OR ROUND SURFACE.    • SOLIDWORK TUTORIAL NO#1| HOW TO MAKE A KNU...   6. CREO 4.0 TUTORIAL NO# 1| HOW TO MAKE A THREADS IN BOLT(HEXAGONAL)    • CREO 4.0 TUTORIAL NO# 1| HOW TO MAKE A THR...   7. SOLIDWORK TUTORIAL NO #5 | HOW TO MAKE A DRILL BIT.    • SOLIDWORK TUTORIAL NO #5 | HOW TO MAKE A D...   8. SOLIDWORK TUTORIAL NO # 6 | HOW TO MAKE A PROPELLER OR FAN BLADE.    • SOLIDWORK TUTORIAL NO # 6 | HOW TO MAKE A ...   9. CREO TUTORIAL # 5 HOW TO RENDER OBJECT IN CREO PARAMETRIC 4.0    • CREO TUTORIAL # 5 HOW TO RENDER OBJECT  IN...   10. CREO TUTORIAL # 6 HOW TO MAKE A SOAP CASE.    • CREO TUTORIAL # 6  HOW TO MAKE A SOAP CASE.   11. CREO TUTORIAL NO #7 ! HOW TO USE TWIST COMMAND & MAKE STRIP.    • CREO TUTORIAL NO #7 ! HOW TO USE TWIST COM...   12. SOLIDWORK TUTORIAL NO #14 / DESIGN AND ASSEMBLY OF SKATE BOARD.    • SOLIDWORK TUTORIAL NO  #14  / DESIGN AND A...   13. SOLIDWORK TUTORIAL NO #16 / BEGINNERS EXERCISE 7.    • SOLIDWORK TUTORIAL NO #16 / BEGINNERS EXER...   14. SOLIDWORK TUTORIAL NO #17 /BEGINNERS EXERCISE 8.    • SOLIDWORK TUTORIAL NO #17 /BEGINNERS EXERC...   ======== #solidwork #HOLEVIZARDFEATURE #SQURETHREAD #threadinsolidwork #howtodrawsqurethread ======== YOU CAN SUPPORT OUR CHANNEL FOR NEW TUTORIAL, WE PROVIDE SOLIDWORK AND CREO PARAMETRIC FREE TUTORIAL. ======== subscribe channel for more tutorial and also share and like video. ======== thanks for watching video..
