How to Use the Grid Drawing Tools | SafeGrid Earthing Software Tutorial скачать в хорошем качестве

How to Use the Grid Drawing Tools | SafeGrid Earthing Software Tutorial

To skip to different earth grid drawing tools, use the video timestamps in Table of Contents below. For more SafeGrid Tutorials, visit: https://elek.com/tutorials/ ▬ Contents of this video ▬▬▬▬▬▬▬▬▬▬ 0:00 - Introduction 0:15 - Background Segments (not used in the calculations) 0:49 - Tags Manager 1:50 - Add Grid 1:57 - Add Polygon 2:11 - Add Rectangle 2:16 - Add Rod 2:31 - Add Segment 2:45 - Array Tool 3:09 - Chamfer Tool 3:15 - Copy Tool 3:33 - Divide at Intersection 3:58 - Extend Tool 4:10 - Move Tool 4:22 - Offset Tool 4:40 - Remove Segment 4:45 - Reverse Tool 5:00 - Rotate in 2D 5:23 - Scale Tool 5:44 - Show Direction 5:51 - Split Tool 6:05 - Trim Tool 6:18 - Snap Tools - Endpoint (hold E key) 6:34 - Snap Tools - Force Connection (hold F key) 6:56 - Snap Tools - Intersection (hold X key) 7:08 - Snap Tools - Midpoint (hold M key) 7:25 - Snap Tools - Orthogonal Mode (hold Shift key) Note: For each drawing command follow the command line prompts in the bottom-left corner of the SafeGrid screen. SafeGrid is software for multilayer earthing (grounding) and lightning protection systems design. For technical information or to Download a Free Trial, visit: https://elek.com/electrical-software/...
