Earth-Rite® MULTIPOINT II Product Overview Video

Welcome to the Newson Gale Earth-Rite® MULTIPOINT II product overview video – our multi-channel static ground monitoring system for processing operations that can generate large quantities of electrostatic charge via the movement of product. Where processes include many metal parts, such as a sieve or fluid bed dryer, there is significant risk that a part may become isolated due to vibration or movement, or that repeat cleaning and reassembly my cause a forgotten or lost ground connection. The MULTIPOINT II utilises an Ex ‘ia’ monitoring signal to safely monitor the ground path of up to eight metal parts being monitored has a connection back to the local verified ground bar to 10 ohms or less. The monitoring panel is stainless steel and Ex ‘ia’ and can be installed in a zone 0/20 – Class 1.2.3 Division 1 area local to the process and ground bar. Connection to the process is via a local marshalling box and single core cable to each part being monitored. The MULTIPOINT II will then verify if each of the parts being monitored has a connection back to the local verified ground bar to 10 ohms or less, meeting with the recommendations of IEC 60079-32-1 and NFPA 77. Visual indication is provided on the monitoring panel for each channel by clear high intensity GREEN / RED, GO / NO-GO LEDs enabling the operator to quickly identify if all parts are grounded or identify which parts has lost a good ground path. In addition to monitoring the ground path of a single process with multiple parts, the MULTIPOINT II can also be utilised to monitor up to eight separate components, for example eight drums by adding 2-pole clamps, cables and local junction boxes incorporating a clamp stowage point. Alternatively, the MULTIPOINT II can be supplied with remote indicator stations which allow for local visual indication at each location and is available in stainless steel or GRP enclosures and provides a high intensity flashing GREEN LED GO or continuous RED LED NO-GO indication for the operator. Newson Gale Limited Video Disclaimer: All images and content shown are for product information purposes only. Our videos are designed to provide you with an overview of how our products are intended to be used and should not be used for general training purposes. You should consider the full product specification prior to purchasing our products to ensure that they are fit for your purposes and not rely on our product overview videos. More than one of our products may be featured in the video at any one time. All information, specification and demonstrations used in the video are based on the latest information available at the time of filming and are subject to change without notice. We have made every effort to display as accurately as possible our products that are available for purchase, however, we cannot guarantee that the information provided will be error-free. Whilst we have taken due care in the preparation of this video and ensured that we have complied with relevant industry standards and guidance, including IEC, CENLEC and NFPA 77, nothing contained herein: • modifies or alters in any way the standard terms and conditions of purchase under the terms of which the equipment and products are purchased from us; • increases in any way our liability to you or to third parties for misuse or neglect by you or the end user; • relieves you, as the end user, of your responsibility to use our products safely and in accordance with the relevant instruction manual; and • assumes any responsibility for us for how you use the products shown in the video. Only Newson Gale Limited and its authorised representatives may use our promotional product information overview videos in advertising and sales materials. All logos referenced within the video, and the videos themselves, remain the property of Newson Gale Limited. For your own safety and the safety of others, and to prevent damage to products, please contact us for the full product information manual and usage guidelines available on groundit@newson-gale.co.uk. It is important that the information provided is read by all persons operating, or coming into contact with, the products to ensure proper installation and use. Should you have any questions concerning the information provided or how to use our products, you can contact us directly on +44 (0)115 940 7500.
