Residential Layout Drawing Preparation - Land Division & Measurements software

With Residential Layout commands, you can prepare residential layouts. You can draw Center Line between Segments and export centerline information to excel. Prepare the Area table of various categories of Plots. Land Division & Measurements software helps you divide the polygon and helps productivity while working on Residential Layout AutoCAD Drawing. Read More: https://esurveying.net/land-division-... Hello everyone, Welcome to the video tutorial about how to use Residential Layout related Functions in the Land Divisions and Measurements Software. With Residential Layout commands, you can prepare residential layouts. You can draw Center Line between Segments and export centerline information to excel. You can do Lot Numbering in a Sequence, and Generate Area Tables. You can also obtain a summary of selected boundaries in a different layer. • CENS command : The CENS command is used to Create Center Lines between Segments, useful for drawing center lines in Roads To execute the command, o Type ‘CENS’ at the command prompt. o Select First Polyline: o Select Second Polyline: The Center Line will be drawn as shown. • EXCN command : The EXCN command is used to To export the centerline information to an excel file To execute the command, o Type ‘EXCN’ at the command prompt. o Select the lines and Polylines For the Residential Layout, the center lines will be numbered and The Length of the selected lines will be displayed, and the details will be exported to an excel file as shown. The excel file shown below will be generated at the location C:\ESurvey\Temp\PLDetails.csv • LNU command : The LNU command is used to Give Numbers to the Plots in a Sequence, along with attributes. To execute the command, o Type ‘LNU’ at the command prompt. o Enter the First Number: o Enter the Second Number: The Numbers will be allotted to the Plot in a sequence as shown. • ATLC command : The ATLC command is used to generate Area Table by Selecting Multiple Lots (with Calculation). It Generates the Area Summary Table for the Plots selected in the Layout. To execute the command, o Type ‘ATLC’ at the command prompt. o Select the Entities: Select all Plots o Select an insertion point to insert the Table. The Area Summary Table for the selected Plots will be displayed as shown. A CSV File “C:\ESurvey\Temp\Area.CSV” is created which will have summary data. • ATML command : The ATML command is used to Area Table from Selecting Lots (Only Area) (ATML) It Generates the Area Summary Table for the Plots selected in the Layout. To execute the command, o Type ‘ATML’ at the command prompt. o Select the Entities o Select an insertion point to insert the Table. The Area Summary Table for the selected Plots will be displayed as shown and a CSV File is created that is C:\ESurvey\Temp\Area.CSV • ATMP command : The ATMP command is used to Area Table from Selecting Multiple Polygons (Only Area) It Generates the Area Summary Table for the Polygons selected in the Layout. To execute the command, o Type ‘ATMP’ at the command prompt. o Select the Entities o Select an insertion point to insert the Table. The Area Summary Table for the selected Plots will be displayed as shown. • PSUM command : The PSUM command is used to Summary of selected boundaries in a different layer (PSUM) It Generates the Area Summary Table for the boundaries selected in the Layout. To execute the command, o Type ‘PSUM’ at the command prompt. o Select the Entities o Select all the Boundaries for the Summary Report: The Area Summary Table for the selected Plots will be displayed as shown. Thank you for watching this video. In this video, you have learned about how to use Residential Layout related Functions. In the next video, you will learn how to do Plot measurements with attributes. Read more: https://esurveying.net/land-division-...
