Concrete block making plant RVP-2000 METALIKA in FONTANA Rokovci fabrika blokova i oplocnjaka

For more info please contact office@metalika.rs or +381628033430 Ivan Vuckovic Concrete block and paver making stationary machine RVP-2000 METALIKA Concrete block and paver making stationary machine RVP-2000 METALIKA is a mid-level highly productive and versatile vibration press machine with latest technology vibration and automatic control systems. Block making machine RVP-2000 is best-selling model with excellent price / quality / capacity ratio. Designed as a compact professional and universal heavy-duty machine, equipped with pallet feeder, two hoppers and dispensers for the concrete, frequency-controlled modern vibration system, automatic controls and conveyor for finished concrete products, RVP-2000 is an excellent standalone or entry level in-line solution with pallet transfer and product handling systems. Main features which are included as standard equipment: • Versatile - wide product range, product height from 25-400mm (350mm for curbs) – with face hopper and face hopper floor lifting to enable production of very thin pavers – from 25mm • Stationary – single pallet with pallet feeder and Conveyor for concrete products on wet side • Mid-level production capacity of concrete products • Hoppers and feeders for face and base concrete mix. • Filler box with pneumatic scraper for concrete residue • Extra rigid machine frame structure made of steel tubes 150x150x8mm, total weight 10t • Precise concrete product height control with four guides of mould • Vibration table with SINHRO 2000 vibration with 2x4kW, synchronized, controlled vibrations for maximum product quality with shortest cycle times. Oil bath enables permanent lubrication and reduces maintenance downtimes. • Tamper head vibration included • GTA control equipment for high productivity and safety (PLC and touch screen panel, high performance hydraulic power pack with two pumps (4kW+11kW), electromagnetic valves, safety sensors). Automatic control unit PLC automatic program for even higher productivity and accurate cycle duplication • Cooling of hydraulic oil and electric cabinet • Tamper head brush on both filler boxes • Electric device - to vertically adjust plates and hoppers for base and face mix concrete when changing molds with different heights • Special steel wear-resistant plates - below filler box on face and base mix • Pneumatic mould clamping – enables faster mould change and better vibration absorption on frame, as well as, better vibration on mould • Mould Change cart – manually driven, are great help when crane is not available • Smart design – does not require service pit under machine. Elevated frame for easy access • Modem link to Metalika technical service department Optional features, possible on demand: • Color mix draw plate and hopper for additional value of products • Agitator with hydraulic drive – rotation device in filler box, with two shafts, to decrease mould filling time when producing hollow blocks • Proportional valves - on concrete filler box to increase speed and durability by enabling smooth movement of filler box • Cross-cleaner brush - to clean tamper head when making curbstones • Draw plate – Core puller device – for special products which have to be shaped on the lower side…TBD • Insertion device for insulation blocks…TBD • Special pallet feeder with pallet lifting – to extend pallet life • Electric device - to open face mix hopper when mould changing or for maintenance purposes Product range: • Paving stones (pavers, slabs, tiles, interlocking and rustic pavers) • Curb stones (kerbs) • Hollow blocks • Solid blocks • Retaining wall elements and similar concrete products • Chimney blocks • Other small concrete precast products Technical data: RVP-2000 Production area / mould size 1130x500mm Product height for pavers and blocks 25-400mm Product height for curbstones (with or without cross-cleaner brush) Up to 250 with cross-cleaner or 350mm without cc Pallet size 1200x550x40mm Face concrete feeder Yes Base concrete feeder Yes Pallet feeder Yes SINHRO 2000 vibrations Yes Cycle time – one layer paver 20x20x6cm 14 sec Cycle time - two layer paver and hollow blocks (with agitator for blocks) 18 sec Capacity hollow blocks 20x20x40cm (8’’)* 4800 blocks/8h Capacity two layer paver 20x20x6cm* 640 m2/8h Operation mode Automatic Power (three-phase) 50Hz 35kW Weight 10t Dimensions LWH (without control cabinet) 9x3,2x3,8m The performance data is based on the 8h production and does not consider an efficiency factor. It is advised to calculate capacity with max 75% efficiency. The performance is dependent on the machine settings, mix designs, aggregates used as well as on other real environmental conditions.
