Creating 3D Fluid Domain Around Body in Ansys Design Modeler by Sketching Method

[Attention: Sorry for the mouse pointer shown a little off during recording in zoom mode] This video shows how to create a simple cube like fluid domain around a body in Design Modeler by using the sketching method. Creating fluid domain by sketching is better than using the 'Enclosure' option because the enclosure option (although being a quick and easy method) has some bugs or inaccuracies, which may result in overlapping surfaces or edges. Note: The front wall of fluid domain should be 1.5-3 times the length of the body along the fluid flow direction. The side should be 2.5-5 times and at the back should be 5-10 times generally. This video has been originally intended to be a quick guide to help a junior university fellow in their cfd based project. #ansys #cfd #domain #fluid #design #modeler
