2017 DMG Mori NHX 4000 CNC Horizontal Machining Center

EQUIPPED WITH: Celos ERGOline Touch Controller 15.7" x 15.7" Pallets 15,000 rpm speedMASTER Spindle Full 4th Axis HSK63 Taper Through-Spindle Coolant Overhead Hydraulics Pallet Edge Locator 40 Tool Magazine Chip Conveyor Renishaw OMP60 In-Machine Measuring Touch Sensor ChipBlaster Tool Break Detection System SPECIFICATIONS: Travels: 22" (560mm) X-Axis Travel 22" (560mm) Y-Axis Travel 26" (660mm) Z-Axis Travel 3.1" - 25.2" Distance Pallet Surface to Spindle Center 2.8" - 28.7" Distance Pallet Center to Spindle Gage Plane Pallet: 15.7" x 15.7" Pallet Working Surface 880 LBS (400kg) Pallet Loading Capacity 24.8" (630mm) Maximum Workpiece Swing Diameter 35.4" (900mm) Maximum Workpiece Height Spindle: 15,000 rpm Maximum Spindle Speed HSK 63 Type of Spindle Taper Hole Rapid Traverse Rate: 2,362.2 ipm (60,000mm/min) X-Axis 2,362.2 ipm (60,000mm/min) Y-Axis 2,362.2 ipm (60,000mm/min) Z-Axis Machine Size: 100" Machine Height from Floor 105.5" x 164.6" Footprint 18,700 lbs Mass of Machine Machine available from Gibbs Machinery Company - Warren, MI USA
