DELTA-UV - Installation & Maintenance - Water treatment for RESIDENTIAL POOLS

We are going to present in a easy and fast way the key facts of a successful installation Before any installation, watch very carefully the explanations on the diagram 1 – DELTA-UV REACTOR INSTALLATION Place the unit in a standing position to realize the bypass. That will allow easier maintenance and permit the water entrance which must be driven from the bottom and the water exit which must be driven from the top. In the technical local, install the unit and realize the bypass. Place the pipe joints with a sealing edge. Making sure to place the transparent joint on the top. It will serve as an operating indicator. Screw in the inlet and the outlet without any tools 2 - INSTALLATION OF THE COMBIPOOL -Place the sleeve where all the injection valves are ready installed and the valve which concerned the pH analyst probe. Notice that both injections are opposite on the same valve. Connect the prop with the unit Unscrew the front face Place the opac polyethylene on the injection valves and then, after positioning the strainers putting them in the corresponding drums, put the PVC crystal pipe on the aspirating troops. Be careful! You have to respect each jump according to every regulation. Fix your front face again. The electrical connection is going to proceed through the filter and control box. Dismount the unit. Check your two plugs and then you're going to connect your units on the A1 and A2 filtration plots which are located in the filtering control box and then connect the combipool After installing on the wall the left technical ballast supply, you can then connect the UV reactor then you start the entire installation. You will notice that your UV lamp is switch on through the white transplant pipe. The doting pump is now connected 3 – STARTING UP THE COMBIPOOL Unscrew the front face again Take the battery off and insert it on its connector This battery is a running reserve. Fix it inside the unit as shown and switch on again your combipool. the elements will be displayed, and the calibration is going to be made. Close the front face. Now all is now ready! You can observe perfect installation. 4 – CHANGING THE DELTA-UV LAMP The UV reactor maintenance in easy and fast. You need to unplug or to disconnect the unit first. This is very essential. Drain the water from the bottom of the unit either by in screwing the nuts or through the drainage cone which just on some units one so unit is empty. Unscrew the top and you carefully take out the unplug UV lamp Be careful to keep the UV lamp very straight by pulling it out gently not to break it Screw the sealing nut Take out the quartz sheath and clean it with some white vinegar and a soft rag in order to remove the limestone. Take place the quartz sheath in the unit by putting your finger inside so that it will be perfectly fit in the hole which is located at the bottom of the unit. Screw back again the sealing nut without forgetting to put the joint back. Reinsert the lamp and reconnect it. This one has an arranged slot which will prevent from positioning it in the wrong side. Do not force it ! The four pins have to go in the connector by themselves. Place your top back on the unit. 5 – INSTALLATION OF THE BIO-UV TEMPO DOSING PUMP AND THE BIO-UV PH AUTOMATIC REGULATOR (for systems which are composed of it) The two units are plugged separately. First, instal the BIO-UV tempo on the wall which provides small doses of active oxygen every day. Then, install the BIO-UV pH automatic régulator respecting carefully the inspiration and injection pipes. Follow us! Web site : https://en.bio-uv.com/ Facebook :   / biouvgroup   Linkedin :   / bio-uv-group   Twitter :   / bio_uv_group
