Let’s Build an FPV Drone – Part 3 Electronics

With the frame assembled, it’s time to bring this drone to life! In this video, we’ll install and wire up the core electronics: • RunCam Phoenix 2 Nano FPV Camera • MicoAir743 V2 60A Bluejay 30×30 FC & ESC Stack • MicoAir M10G-5883 GPS • TBS Unify Pro HV 5G8 Video Transmitter • RadioMaster 2.4GHz RP1 ELRS Nano Receiver I’ll walk through the electrical connections and placement of each component inside the iFlight Protek 3.5 frame, setting the stage for tuning and flight testing in future steps. For detailed documentation and materials list, visit my GitHub repository: https://github.com/timarcher/FPVDrone Timestamps 0:00 Intro 00:59 Electronics Overview 17:06 Frame Modifications 25:47 ESC Wiring 34:14 ArduPilot Motor Test 58:43 ESC and Flight Controller Mounting 1:11:05 USB-C Port Mounting 1:15:02 RunCam Installation 1:40:51 Video Transmitter and Receiver Mounting 1:59:10 Minor Modifications Post Video
