Automated External Thread Verification with an IND Station

A Fully Automated IND Thread Verification Station Inspecting the External Threads on M10 Machine Screws. For Information about New Vista's Automated Stations, visit: https://www.newvistacorp.com/products... VIND10 The part has an M10 male thread. Cycle time is 2.8 seconds. Parts are introduced through a vibratory infeed. Parts are indexed to the verification position. Here is a bad part. The part fails the "GO" test. A second "GO" test is attempted. Good parts are ejected through a "Good Parts Chute." Bad parts are ejected through a "Rejects Chute." INDs are also tooled for Female Threads.
