Custom 4-Hole Punch Tool for FI125 Ironworker | Power, Precision & Productivity

At Scotchman Industries, custom tooling is all about helping fabricators work faster, cleaner, and more efficiently. This custom punch tool is a perfect example—engineered to deliver power, precision, and productivity on an FI125 ironworker. Designed to punch four holes simultaneously in up to 3/8” mild steel, this tool maximizes output without sacrificing accuracy. In the video shown, the tool is punching 9/16” × 1-1/8” oval holes using a shear top punch, producing clean, consistent results while operating at maximum rated tonnage through 3/8” × 6” wide mild steel. Key Design Features Fixed 4” center-to-center hole layout Individually adjustable die holders for precise alignment Built to handle full tonnage demands of the FI125 Heavy-duty construction for long-term reliability Flexibility was a major design focus. The punches can be rotated 90°, and the tool accommodates virtually any hole shape using standard #40 punches and #82 dies. For improved material handling, the stripper assembly can be reoriented for left-to-right feeding, allowing the tool to adapt to different shop layouts and workflows. A custom stop was added to the stripper plate to ensure consistent positioning and repeatable results. This feature can be tailored to the specific application, further improving efficiency and accuracy during production runs. Custom Solutions Built Around Your Process This project highlights how Scotchman’s custom tooling solutions are designed around real-world fabrication needs. From multi-hole punching to application-specific layouts, our team works closely with customers to create tools that integrate seamlessly with their ironworker and production goals. 📞 Need custom tooling? 605-859-2542 #metalfabrication #Ironworker #CustomTooling #FI125 #SteelFabrication #ShopEfficiency #Manufacturing
