How to Install a Proper Grounding System for Electric Fence (Earthing System Explained)

In this video, we cover one of the most important — and most commonly misunderstood — components of any electric fencing system: the grounding system (also called the earthing system). Your hot wires are only half the circuit. When an animal touches a hot wire, the shock only happens if the current can travel back to the energizer through the ground system. If your grounding is inadequate, your fence will not deliver the full shock your energizer is capable of producing. Poor grounding is the single most common cause of underperforming electric fences. Why Grounding Matters When livestock contact a hot wire: Current flows through the animal Travels through the soil Returns to the ground rods Completes the circuit back to the energizer If the ground rods cannot effectively collect those returning electrons, the shock will be weak — even if your fence voltage appears adequate. Materials You Should Use (And What to Avoid) Use: 6 ft galvanized steel ground rods Galvanized insulated electric fence hookup wire (12.5 gauge or similar) Purpose-built ground rod clamps Avoid: Rebar (corrodes and becomes less conductive) Household electrical wire (insulation rated for only 600 volts) Electric fences operate at 7,000–10,000 volts. Household wire insulation will eventually leak and short out in these conditions. Always use fence-specific insulated hookup wire. How Many Ground Rods Do You Need? Minimum recommendation for permanent systems: At least three 6 ft ground rods General rule of thumb: 3 feet of ground rod per joule of energizer output Add one 6 ft rod for every additional 2 joules beyond six joules Large energizers may require 10–15 ground rods. That may seem excessive, but your ground field must be large enough to receive all returning current under heavy load. Ground rods should be: Spaced 10 feet (3 m) apart Connected with one continuous insulated wire Installed in an area protected from livestock and machinery Driven slightly below soil surface to prevent damage Think of your ground rods as an antenna array underground. The larger the array, the more effectively it collects returning energy and completes the shock. Driving and Installing Ground Rods We demonstrate: Driving rods using a post driver and sledgehammer Installing rods slightly below grade Burying hookup wire shallowly to prevent damage Maintaining one continuous ground wire through all rods When wiring rods together: Strip insulation carefully without damaging the conductor Bend and double the wire for increased contact surface Use proper ground rod clamps Tighten securely for solid mechanical and electrical connection All ground rods are wired together with one continuous insulated conductor, ensuring minimal resistance. Connecting to the Fence The final step is connecting the ground system to the fence ground wires or directly to the energizer ground terminal. Every electrical connection — hot or ground — should use a mechanical joint clamp. Twisting wires together is not sufficient. Poor connections create resistance and reduce fence performance over time. We also demonstrate: Proper stripping technique for heavy insulated hookup wire Creating slack to prevent tension damage Securing wire neatly and safely to posts Extending Your Ground Field In this installation, we added 18 feet of ground rods in a new pasture approximately one kilometer away from the main ground field. As fencing systems expand across a farm, additional grounding arrays may be necessary to maintain performance over long distances. The Bottom Line If your electric fence is underperforming, start by evaluating your grounding system. A properly sized energizer cannot compensate for inadequate grounding. Use the right materials. Install enough rods. Space them correctly. Wire them continuously. Clamp every connection securely. A strong grounding system is the foundation of a reliable electric fence. If you're serious about electric fencing, mastering your grounding system is essential to consistent, effective livestock control. Related Videos in This Series How to Test and Size Your Energizer and Grounding System    • How to Install a Proper Grounding System f...   Electric Fence Fault Finding: Tools + How to Track Down a Short    • Electric Fence Fault Finding: Tools + How ...   High Tensile Electric Fence Layout & Design    • High Tensile Electric Fence Layout & Design   For more, check out our: Rotational Grazing Playlist    • Rotational Grazing   Electric Fencing Playlist    • Electric Fencing   Subscribe for more fencing and grazing education: https://www.youtube.com/c/SmallScaleM...
