Wiring and Programming the CNPT Series Controller for PID Control

We get a lot of questions about different wiring configurations of our Omega CNPT Series Controllers – And in THIS video we’ll configure a CNPT for PID control. The Omega CNPT Platinum Series, microprocessor based PID controllers offer unparalleled flexibility in process measurement and control. And in this video we’re going to set-up a CNPT Process Temperature Controller for PID Control. Chapters: 00:00 Introduction 00:22 About the CNPT Platinum Series PID Controller 00:30 Link to mechanical relay to on/off control video 00:45 Products/materials used in this demonstration 01:15 Wiring the CNPT 02:10 Programming the CNPT for type T thermocouple 02:44 Setting annunciator 1 and DC output on the CNPT 03:15 Programming the set-point 03:50 Setting DC1 output to PID 04:13 Setting reverse action for heater control 04:22 Setting up and running auto tune 04:51 Running autotune 05:01 Annunciator synched with relay - cycling power to control heater 05:08 So there you have it! Links to DwyerOmega products used in this video: CNPT Controller: https://www.dwyeromega.com/en-us/1-32... SSRL Solid State Relay: https://www.dwyeromega.com/en-us/soli... SA1-T Surface TC Probe: https://www.dwyeromega.com/en-us/self... KHA Series Flexible Heater: https://www.dwyeromega.com/en-us/self...
