How to Add Arduino UNO Footprint PCB Package on Proteus 8 | R1 | R2 | R3

Click CC to select English, Malay, Indonesia, Filipino and Hindi subtitles. Description: This video demonstrates how to add the Arduino UNO footprint PCB package on Proteus 8 software. The PCB package is created by me and interface with Arduino UNO from TEP. The dimension of the PCB package is based on Arduino UNO R1, R2 and R3, as mention in the references. Download Arduino UNO PCB package below: References: 1. https://blog.arduino.cc/2011/01/05/ni... 2. http://www.rcbasseterre.fr/arduino-un... Arduino UNO PCB Package: https://drive.google.com/file/d/1ZmVm... Time Stamp: 0:00 Intro 0:18 Open PCB package file 0:24 Make package 1:48 Adding PCB package/Assign package 3:25 Test 3:45 End screen Social Media: Youtube:    / mycreativ3   Facebook:   / mycreativ3   Twitter:   / mycreativ3   Instagram:   / mycreativ3   Blogger: https://my-creative-engineering.blogs... Credit song: Lonely Dance by Vexento Music: Lonely Dance - Vexento    • Vexento - Lonely Dance   A New Beginning by Benjamin Tissot Music: A New Beginning - Benjamin Tissot https://www.bensound.com #footprint #arduino #R1 #R2 #R3 #pcbpackage #proteus8
