0034: Instruction Register Breadboard | 16-Bit Computer From Scratch

CircuitVerse Project Link: https://circuitverse.org/users/160845... 16-Bit Computer From Scratch Complete Playlist:    • 0001: Very First Surface Mount Soldering |...   16-Bit Computer From Scratch Intruction Cycle Complete Playlist:    • Instruction Cycle Modules   16-Bit Computer From Scratch Register Module Playlist:    • 0008: Basic Register (Data Storage) | 16-B...   Chapters: 0:00 Intro 0:22 Tour of the Processor 1:17 The Instruction Register 2:11 IC Placement 4:52 Power, Ground, and Control Signals 6:08 First Bit Wire-Up 7:59 Complete Wire-Up 12:49 How to Control Timing? 15:12 Current Timing Problems? 16:55 Captioning 17:20 TODOs In this video I breadboard out the Instruction Register and perform some surface testing. I also discuss some methods for aligning the control signals, as the timing of these signals is dependent on the number of gates that the signal needs to go through. We need to understand how to effectively close any gaps that are needed. Additional Tags: #Homebrew #Breadboard #PCB #KiCad #74LS #IC #SMD #schematic #CircuitVerse
