[Touch] Capacitive Touch Sensing Shields | 4-Key & Wheel BMK56T004 | 4-Key & Slide BMK54T004

📌4-Key Wheel Capacitive Touch Sensing Shield BMK56T004 📌4-Key Slide Capacitive Touch Sensing Shield BMK54T004 💻https://www.bestmodulescorp.com/input... 00:00 00:07 [Touch] Capacitive Touch Sensing Shields | 4-Key & Wheel BMK56T004 | 4-Key & Slide BMK54T004 00:08 00:24 BMK56T004 Reduce power consumption 00:25 00:41 Wheel Touch Sensing Shield Features 00:42 01:47 Wheel Touch Sensing Shield PIN Description 00:48 01:14 Wheel Touch Sensing Shield DEMO 01:15 01:36 Wheel Touch Sensing Shield with Arduino 01:37 01:55 BMK54T004 Reduce power consumption 01:56 02:10 Slide Touch Sensing Shield Features 02:11 02:15 Slide Touch Sensing PIN Description 02:16 02:45 Slide Touch Sensing Shield DEMO 02:46 03:07 Slide Touch Sensing Shield with Arduino 03:08 03:23 Product Notes 03:24 03:28 www.BestModulesCorp.com ✒Description The BMK54T004 is a capacitive touch sensing development board integrated by 4 touch keys and one slide touch pad. It has a built-in Holtek 8-bit MCU BS83B16C and provides excellent anti-interference ability. When a finger touches the copper trace area on the PCB representing the switch area, the capacitance of this area will change. The product determines the output status of the INT pin by detecting this change. The slide touch pad is composed with 8 touch keys. With the unique PCB touch area layout design and MCU software algorithm, it has the advantage of stable and fast touch location recognition. The corresponding LED light up when sensing the touch. Touch keys’ sensitivity can be adjusted individually. There are BMduino interface on the reverse side of the board. It's recommended to use the product with the BMduino UNO. You don't need an external cable, just connect the two via the BMduino interface. The BMK56T004 is a capacitive touch sensing development board integrated by 4 touch keys and one wheel touch pad. It has a built-in Holtek 8-bit MCU BS83B16C and provides excellent anti-interference ability. When a finger touches the copper trace area on the PCB representing the switch area, the capacitance of this area will change. The product determines the output status of the INT pin by detecting this change. The wheel touch pad is composed with 8 touch keys. With the unique PCB touch area layout design and MCU software algorithm, it has the advantage of stable and fast touch location recognition. The corresponding LED light up when sensing the touch. Touch keys’ sensitivity can be adjusted individually. There are BMduino interface on the reverse side of the board. It's recommended to use the product with the BMduino UNO. You don't need an external cable, just connect the two via the BMduino interface. 🏢 Best modules corp. 🔗2F, 19, Innovation First Road, Hsinchu Science Park, Taiwan 30076 🤝service@bestmodulescorp.com #InputModules #InputSensor #TouchSensorModules #WheelCapacitiveTouchSensor #4KeysTouchSensor #電容式觸控感測模組 #觸控感測模組 #觸控模組 #滾輪型觸碰控模組 #MIT #MCU #TaiwanMCU #Shield #DustproofTouchSensor #Arduino #WaterproofTouchSensor #防水觸控面板 #Scratch-resistant觸控 #耐刮擦觸控 #InsulationprotectionTouchSensor #絕緣保護 #AgainstElectricShocks #防觸電
