Air Source Heat Pump Wiring - Panasonic Aquarea k & L Series 2025 UK

I put this video together to offer the growing number of Electricians who are now becoming involved in wiring the Panasonic Aquarea air source heat pumps some suggestions on how the system could be wired as both the K and the L series are wired in similar fashion. The scenario with our K Series unit is the Controller is being used as the Room Thermostat so on site the only slight change would be to either still use the controller as the main thermostat which I prefer by removing it from the front panel and locating it in a central location and then use a 2 core comms cable to wire it to the PCB. A blanking cover can then go in place of where the controller was originally mounted. Option 2 could be as a suggestion to use a run signal from your Heatmiser wiring centre LS and LR and wire that back to the PCB with 2 Core comms cable. The schematic diagrams also suggest additional options for Clients requiring additional controls. For Installation Companies using our MCS Umbrella Services we provide the Manufacturer’s schematics for the Electrical wiring along with the suggested fuse sizes, cable diameter sizes and a full colour schematic highlighting where all cables connect. As part of our Scope of Services within our Umbrella Scheme we offer technical support via site visits wherever possible unless distance is a challenge, telephone calls and email support. Please drop us an email at info@air2heat.co.uk for a quotation or to discuss your project in more detail or send us a message via the link below. If your project is eligible we will also apply for your Boiler Upgrade Scheme grant of £7,500.00 which is the Government Grant towards the cost of your Installation. 🌟 Send Us A Message via https://www.air2heat.co.uk/contact 🌟 Please note: Some information in this video may differ slightly with releases of newer schematics and manuals as time goes by so please check with us if you have any questions going forward as there may be some updates. #heatpump #panasonic #bestheatpump #airsourceheatpump #efficientheating #renewableenergy #decarbonisation #energyefficiency #efficiency #heatpumpwiring #PanasonicAquarea #commercialheating #MCSUmbrellaScheme
