ST620 Track Screening Plant

Lokotrack ST620 mobile screen Lokotrack ST620 mobile screen is specially designed for applications that require very high performance, efficient fine screening and good mobility. Metso Minerals, the world's leading crushing and screening equipment manufacturer, has developed this track-mounted screening unit, the ST620, for high performance and excellent mobility over a large range of screening jobs. The ST620's high screening capacity and easy adaptability to different crushing and screening processes guarantee its suitability for a wide range of applications among contractors and quarry operators. The ST620's frame is the same strong, robust frame used in the world-acclaimed LT mobile rock crushing units. The screening unit is also equipped with discharge conveyors for four separate products sizes. The powerful diesel engine ensures efficient and independent screening in all conditions. Easy to operate. The Metso ST620 is extremely easy to operate. One push of a button actuates the advanced Programmable Logic Control (PLC), which automatically starts the whole screening process. Lokotrack ST620 is ideal for: classification at applications requiring constant, high capacity multi stage crushing and screening operations with other Lokotracks Main customer benefits of the Lokotrack ST620 are: • large, three-deck, dual-slope screen for high capacity; • user friendly with "one button" process start up; • enables accurate classification of four end products; Main features of the Lokotrack ST620 are: The ST620's DS series high-performance triple-deck screen has been specially designed for mobile applications. High capacity is guaranteed by a large screen deck area for all three decks and a steeper inclination angle at the loading end. Screening accuracy, in turn, is ensured by a shallower angle at the discharge end. The hydraulically driven screen can be equipped with a wide range of screening meshes to suit different product sizes and requirements. Technical specifications Screen deck area (three deck screen): 19'8"x5'11" (6.000 mm x 1.800 mm) Screening area per deck: 112 sq.ft. (11 m2) Lifting and discharge conveyor belt width: (3'11") (1.200 mm) Side conveyor belt width: (2'7") 800 mm Engine power: (175bhp SAE) (130 kW) Transport dimensions Length: 48'9" 14.850 mm Width: 9'10" 3.000 mm Height: 12'5" 3.800 mm Weight, chassis: 60,720 lbs 27.600 kg Weight, 3 side-conveyors: 8,580 lbs 3.900 kg Contact e-mail: sales@mellotts.com for information and quotes.
