Stop Guessing! How to Diagnose Videojet Encoder Failures with Arduino Mega

Struggling with a Videojet 6530 Carriage Position Error? Stop guessing and start diagnosing. 🛠️ In this TTOParts Masterclass, we show you how to build a professional-grade Encoder Tester using an Arduino Mega. A faulty encoder is one of the most common (and frustrating) causes of carriage errors and blurry prints on Videojet 6530, 6330, and Linx TT 1000 printers. Instead of "parts-cannoning" expensive motors, we’ll show you how to see the digital heartbeat of your machine in real-time. In this video, you will learn: The root cause of the Videojet 6530 Carriage Position Error. How Quadrature Encoders work (Theory of Channel A Channel B) How to wire an Arduino Mega to a 16x2 I2C LCD for diagnostic feedback. A deep dive into the Arduino code using Hardware Interrupts for 100% accuracy. How to differentiate between a healthy encoder and a failed unit. 📍 Timestamps: 0:00 – Intro 0:55 – What you need 1:24 – Encoder Theory: Pulses, PPR, and 4x Decoding 2:00 – Software Masterclass: Using Interrupts for Precision 2:52 – Setup 3:40 – Testing 5:55 – Outro 🔧 Parts List for this Build: Microcontroller: Arduino Mega 2560 Display: 16x2 LCD with I2C Backpack Connecting: Jumper Wires & Breadboard Unit Under Test: Videojet 6530/6330 or Linx TT 1000 Motor https://ttoparts.com/products/407873-... 🔗 Resources & Links: Download the Code & Schematic: www.ttoparts.com Need Replacement Parts? Shop Videojet & Linx compatible encoders here: [ Watch our Short on the specific 6530 Repair:    • Videojet Printhead Stuck? How to Fix Carri...   About TTOParts: We specialize in high-quality, reliable parts for Industrial TTO Printers. Our mission is to provide technicians with the tools and knowledge to minimize downtime and maximize print quality. Don't forget to SUBSCRIBE for more industrial repair masterclasses! #Videojet6530 #CarriagePositionError #Arduino #EncoderTester #TTO #Maintenance #IndustrialPrinting #LinxTT1000 #TTOParts #Engineering
