Single phase motor speed controller using potentiometer, 0-10V or RS485 modbus RTU.

JLCPCB 1-20 Layer PCB from $2, Sign up to Get $54 Coupons here: https://jlcpcb.com/?from=MrI Hello friends in this video I have developed a single phase motor speed controller card. this card has the option to control speed via potentiometer, 0 to 10V DC or RS485 Modbus RTU protocol. This can handle up to load of 1KW single phase induction motor. the principle of speed control is based on zero cross over detection and triac firing. code, schematic & PCB file https://drive.google.com/file/d/10ygF... Caution. 230V AC voltage is involved in this project. Text to speech generated using elevenlabs.io 💻visit for more projects :- 👉 Short channel :-    / @mrinnovativeshorts   👉 instagram :-   / mrinnovative01   👉 Website :- http://electricdiylab.com/ 👉 FB page :-   / innovativemr   I use Epidamic sound for my back ground music if you like it you can check them out https://www.epidemicsound.com/referra... ** This video is made for educational purposes only. Please use your own judgment, knowledge, care, and precaution if you plan to replicate. ** WhatsApp for custom projects +91 7600079068
