CimatronCAM Tutorial 2: Filter Commands

Filter commands in Cimatron CAD/CAM software are tools or functions that allow users to select and manipulate specific elements or entities within their design or manufacturing project. These filters help streamline the design and editing process by enabling users to isolate and work on particular components. The specific filter commands available can vary depending on the Cimatron CAD/CAM software you are using. I'll provide some common filter commands and their general functionalities, but keep in mind that the exact names and capabilities may differ between software applications: Selection Filters: These filters allow you to choose specific types of objects for editing or modification. Common selection filters might include: Entity Type: Select lines, arcs, circles, polygons, etc. Color: Choose objects with a particular color. Layer: Select objects on a specific layer. Material: Pick objects based on their material properties. Geometric Filters: These filters enable you to target objects based on their geometric properties: Size/Length: Select objects based on their dimensions or length. Angle: Choose objects with specific angles. Radius: Select objects with a particular radius. Entity Filters: These filters help you select entities by their specific properties: Endpoint: Select objects based on their endpoints. Midpoint: Choose objects using their midpoints. Center: Select objects based on their centers. Layer Filters: These filters allow you to isolate objects on specific layers for editing or visibility. Attribute Filters: Cimatron CAD/CAM software uses attributes or properties for objects, you can use these filters to select objects with particular attributes. Boolean Filters: These filters let you combine selections using Boolean operations like Union, Intersect, or Subtract. Group Filters: If you've grouped objects together, you can use filters to select entire groups. Dynamic Filters: Cimatron CAD/CAM software provides dynamic filtering options, allowing you to create custom filters based on various criteria. Named Filters: In Cimatron software, you can save and reuse filter settings, which is helpful for recurring tasks. #cnc #cncmachining #instamachinist #manufacturing #machining #engineering #cncmilling #machinist #woodworking #milling #cncmachine #design #cncporn #machineshop #d #fabrication #cncrouter #wood #cncmachinist #tools #metalworking #cncmill #metal #lasercutting #welding #machine #laser #cncwoodworking #lathe #cadcam #manufacturing #cimatron
