Batocera CRT 240p with Intel integrated graphics processor

UPDATE3: I wrote this guide for GroovyMAME on BATOCERA 31: https://docs.google.com/document/d/1y... UPDATE2: I wrote this guide for BATOCERA 31 https://docs.google.com/document/d/1o... UPDATE1: Rion (    / @rionredemp83   ) sent me this: https://wiki.batocera.org/batocera-an... which is a step by step guide to enable 15KHz on Batocera. All instructions here in the description using timestamps Summary: Configuring Batocera on a small PC: Intel I3 + Intel integrad graphics processor to be used with a Sony PVM at 480i (menu) and 240p (games). Preparation: 1.- Download Batocera and flash it to a USB flash drive. I used batocera-5.27-x86_64-20200912.img.gz 2.- Configure your PC BIOS to boot from the USB flash drive. 3.- Donwload Putty or similar to access your PC using SSH (console) via the network. In my case the PC is connected via Ethernet. 4.- Connect your PC to your CRT (I use a VGA port and an UMSA adapter - RGBHV to RGBS) Let's start: ************************* 00:00 Booting first time It should boot at a non-supported resolution ************************ 00:32 Connect via SSH Get the IP address doing "ping batocera" in a command line window username: root password: linux ********************************** 01:10 Get your monitor/TV name: xrandr -display :0.0 | grep " connected" VGA-1 connected primary 720x480+0+0 (normal left inverted right x axis y axis) 0mm x 0mm *********************************** 01:22 Add the 480i video configuration cp /etc/X11/xinit/xinitrc ~/.xinitrc Edit .xinitrc and after: change the resolution and the Hz xrandr -s 640x480 -r 60 Add (replace VGA-1 with your display name) xrandr -display :0.0 --newmode "NTSC-DVD-60i" 13.514 720 736 800 858 480 484 492 525 Interlace xrandr -display :0.0 --addmode VGA-1 "NTSC-DVD-60i" xrandr -display :0.0 --output VGA-1 --mode NTSC-DVD-60i xrandr -display :0.0 --output VGA-1 --transform 1,0,-40,0,1,10,0,0,1 Last line in case you want to move the image : -40 (right) 10 (up) Now you can reboot, everything should be at 480i ******************************************************************************* 03:40 Change Retroarch menu driver to RGUI and select the right video output Edit batocera.conf, add the following configuration: global.videooutput=VGA-1 global.integerscale=1 global.smooth=0 global.retroarch.menu_driver=rgui Reboot to apply changes. ****************************************** 05:09 Configure CRT switchres per core Now, choose any core and game inside Batocera using your gamepad or keyboard. Example: Core: Atari 2600 Game: H.E.R.O. Access the menu and configure (in this order): Main Menu -- Settings -- User Interface -- Show Advanced Settings [ON] Main Menu -- Video -- Bilinear Filtering [OFF] Main Menu -- Video -- Scaling --Integer Scaling [ON] Main Menu -- Video -- Scaling --Aspect ratio 4:3 (you can change that later) Main Menu -- Video -- CRT SwitchRes -- Use custom Refresh Rate [ON] Main Menu -- Video -- CRT SwitchRes -- CRT Super Resolution: 1920 Main Menu -- Video -- CRT SwitchRes -- CRT SwitchRes [ON] It should change to 240p Now you can adjust your scaling in: Main Menu -- Video -- Scaling Finally, save the configuration for this core: Quick Menu -- Override -- Save Core overrides Do the same with other cores ******************************** 06:45 Enjoy!!!
