LoRaWAN planning with RadioPlanner 3.0

Get free trial at https://www.wireless-planning.com Time codes 00:00 - Intro 00:22 - Main System Parameters 01:27 - Sensor and Base Station Parameters 02:18 - DTM and Clutters 02:38 - Propagation Model 03:18 - Prediction Types 04:41 - Point Analysis 05:33 - Compare Coverage Menu 06:35 - Save Coverage 07:46 - Reports 08:11 - Detailed Calculation in the Fixed Wireless Access Menu 09:24 - Coverage prediction for Individual Sensors RadioPlanner 3.0 is a planning tool for various types of networks, including: LTE / 5G (NR) mobile and fixed wireless access (FWA) networks Public safety land mobile networks: P25, TETRA, DMR, dPMR, NXDN Wireless IoT LPWAN networks: LoRa, SigFox, NB-Fi Precision agriculture systems Terrestrial radio and television broadcast networks: ATSC, DVB-T, DVB-T2, ISDB-T, DTMB, DAB, DAB+ Air-to-ground communication and radio navigation systems operating in VHF, UHF, and microwave frequencies: UAV (Drone) Control, Air-to-ground radio, ADS-B, VOR, DME RadioPlanner 3.0 uses propagation models: ITU-R P.1812-6 ITU-R P.1546-6 Longley-Rice (ITM) v1.2.2 Okumura-Hata 3GPP TR 38.901 Combined ITU-R P.528-3 + P.526-14 (for Ground-to-Air Radio only) RadioPlanner 3.0 performs various types of area studies for mobile networks: Received Power Best Server (Strongest Server) C/(I+N) Ratio Maximum Throughput Maximum aggregated Throughput Area with Signal above Both Base and Mobile Thresholds Number of Servers Coverage Probability RSRP for LTE and 5G RSRQ for LTE and 5G Simulcast Delay Spread Received Power with Simulcast Interference TalckOut and TalckBack Field Strength Area studies for terrestrial radio and television broadcast transmitters include: Field Strength at Receiver Location Best Server Simulcast Delay Spread FCC contours ITU-R P.1546-6 contours Population coverage Generation of list of localities covered by broadcasting Area studies for Air-to-Ground radio communication systems include: Received power Air-to-Ground link Received power Ground-to-Air link Best Server Air-to-Ground link RadioPlanner offers the following features: Work with multiple networks within a single project and view aggregate coverage predictions for maximum throughput and number of servers. Plan radio network frequencies while considering co-channel and adjacent channel interference. Display of path profiles with path losses and levels of carrier and interference on the co-channel and adjacent channels. Perform multipoint study of a group of CPE or IoT sensors (end devices), each with their individual parameters (antenna height, antenna gain, transmitter power, cable loss, and penetration loss) under varying deployment conditions. Import measured signal power level results for comparison with calculated values and adjust propagation model parameters. Compare multiple coverage prediction results. Save coverage prediction results as an interactive web page, KMZ file, PNG image, GeoTiff file, CSV file or as MIF file. Flexibly adjust base map layers and display custom vector layers. GIS features: Default digital terrain model (DTM) with 30m plane resolution, automatically loaded worldwide. Option to use custom DTM in GeoTiff format. Default clutter model with nine clutter types, automatically loaded worldwide. Created from OpenStreetMap (www.openstreetmap.org) and Global Forest Change projects. Option to use custom clutter in GeoTiff format. Common (e.g., OpenStreetMap, OpenTopoMap, US Topo) and custom base maps.
