Wire Runs on Bhaile, Bennett Trim Tab Harness Extension & Lumishore Module Layout

Sully’s Mistake Factory – Season Two, Episode Two Episode Two of Season Two takes us from onboard Bhaile into the shop as we continue building this system the right way — clean, serviceable, and fully aligned with ABYC best practices. We start onboard tracing existing wire runs and evaluating routing, support, and protection before extending the Bennett Marine Trim Tab wiring harness. Rather than splicing blindly, we walk through: • Proper conductor sizing verification • Maintaining color code consistency • Waterproof termination methods • Heat-shrink crimp connections vs open barrel • Securing and supporting harness extensions • Avoiding voltage drop issues in control circuits From there, we shift into the shop to break down the different Lumishore lighting modules that will power this new underwater lighting system. Instead of mounting components wherever there’s space, we step back and engineer the layout. This episode covers: ✔ Planning module placement for serviceability ✔ Ventilation and heat management considerations ✔ Separation of high-current and signal wiring ✔ Clean DC distribution routing ✔ Labeling strategy for future troubleshooting Finally, we fabricate custom mounting panels from marine StarBoard to create a clean, durable, and practical installation surface. No loose modules. No spaghetti wiring. No “temporary” mounts that become permanent. We discuss: • Why panel fabrication matters for long-term reliability • Fastener selection in a marine environment • Mounting height and accessibility • Creating an installation that the next technician will thank you for This season isn’t just about installing underwater lights — it’s about building a marine electrical system that is organized, safe, and scalable. Mistakes were made… now what? Topics Covered Bennett trim tab wiring extension Lumishore module planning Marine wire routing best practices ABYC compliant harness extensions StarBoard fabrication for marine panels Marine electrical organization DC system layout planning Boat refit wiring upgrade #MarineElectrical #MarineElectrical #ABYC #BennettTrimTabs #Lumishore #BoatWiring #StarBoard #BoatRefit #MarineSystems #ABYC #BennettTrimTabs #BoatRefit #MarineSystems #SullysMistakeFactory
