How to use Bearing Connection in PTC Creo Assembly | Bearing Connection Sets Creo Assembly

In this video tutorial, you will learn how to use the Bearing connection to assemble a component to connect a point to a referenced axis so that the component moves along the axis with one translational degree of freedom and three rotational degrees of freedom. Bearing connection is a combination of Ball and Slider connection. While creating a Bearing connection, you need one constraint and one translation axis setting. The Point alignment defines the connection between a point and an axis that the component is aligned to and rotates about. The point reference can be a datum point or vertex. The second reference can be an edge, axis, or curve. The Translation Axis setting defines the component's position along the alignment axis. The reference can be a selected datum point, vertex, datum plane, or planar surface. --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Video Title: How to use Ball Connection in PTC Creo Video Link: https://www.youtube.com/watch?v=FOcXv... Video Title: How to use Slot Connection in PTC Creo Assembly Video Link:    • How to use Slot Connection in PTC Creo Ass...   Video Title: How to use Intelligent Fasteners Extension in PTC Creo Video Link: https://www.youtube.com/watch?v=eqQOX... --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- If you learned something from this video, please give it a thumbs up. If you like this video, please click the Subscribe button to be informed when new videos are uploaded. Also please write a comment if you would like to see more videos like this. Hashtags: #SCANtoCAD #PTCCreo #BearingConnection #CreoAssembly #CAD #3DModeling
