How to use Planar Connection PTC Creo Assembly | Planar Connection Set

In this video tutorial, you will learn how to use the Planar Connection to assemble a component to a referenced planar surface so that the component moves along that plane with three degrees of freedom. In the Planar connection, there are two degrees of freedom in the referenced plane and one degree of freedom around an axis perpendicular to it. While creating a Planar connection, you need one constraint and three motion axis settings. The Axis Alignment constraint defines the parallel plane that the component moves along. The constraint is a single planar mate or aligns constraint that can be flipped or offset as required. The reference can be a selected planar surface or datum plane. You can use the Translation Axis 1 and Translation Axis 2 axis settings to define translational motion settings in the first and second direction for the connection, such as the zero position, regenerated position, minimum limits, and maximum limits. The Rotation Axis is the third motion axis setting, you can use this rotational motion axis element to define rotational motion settings for the connection, such as the zero position, regenerated position, minimum limits, and maximum limits. --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- Video Title: How to use Slider Connection in PTC Creo Video Link:    • How to use Slider Connection in PTC Creo A...   Video Title: How to use Bearing Connection in PTC Creo Video Link:    • How to use Bearing Connection in PTC Creo ...   Video Title: How to use Ball Connection in PTC Creo Video Link: https://www.youtube.com/watch?v=FOcXv... Video Title: How to use Slot Connection in PTC Creo Assembly Video Link:    • How to use Slot Connection in PTC Creo Ass...   --------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- If you learned something from this video, please give it a thumbs-up, and please click the Subscribe button to be informed when new videos are uploaded. Also please write a comment if you would like to see more videos like this. Hashtags: #SCANtoCAD #PTCCreo #PlanarConnection #CreoAssembly #CAD #3DModeling
