Run a specific curve on PU90 ramp and soak profile PID Controller

Ramp Soak Controllers. This type of controllers changes the setpoint according to the preset program pattern. The program consists of raising/reducing the setpoint (ramp control) and keeping the setpoint at the preset level for a preset period (soak control) This is a video tutorial on how you can run a specific profile on PU90 ramp and soak profile PID controller 1) There is a simple heating system in the video consists of solid state relay, a light bulb and temperature controller as well as a PT100 temperature sensor. 2)The program executed in the video is a 6 steps program, starts from 0 degree to 30 degree within 5 seconds, step 2 would be hold the temperature at 30 degree for 3 minutes, step 3 bring the temperature from 30 degree to 50 degree within 5 minutes, Step 5, hold the temperature at 50 degree for 3 minutes, Step 6, increase the temperature from 50 degree to 80 degree within 5 minutes and then program stop right there. 3)You can see over the course of the entire program, the temperature and time are changing as per profile pre-programmed. This item is perfect for kiln, oven, furnace, and all kinds of devices that require precise temperature and time control .
